Room Carbon Dioxide (CO2) Transmitter PL-RM-C02, PL-RM-C02-LCD
The room CO2 transmitter device uses a highly accurate and reliable nondispersive infrared (NDIR) sensor in an attractive, low profile enclosure for room applications to monitor CO2 levels. The sensor uses dual wavelength optics and LTA (long term adjustment) signal processing technology to deliver industry leading long-term accuracy and reliability.
Product Code: PL-RM-CO2*
*See "Screen Options" below for the right product code according to the desired configuration
Characteristics
Gas Type Detected: Carbon Dioxide (CO2)
Sensor Type: Dual channel non-dispersive infrared (NDIR)
Measurement Range: 0-2000ppm, adjustable 1000 – 10000ppm
Sensor Accuracy: ± (30ppm + 3% of measured value)
Output Signal Type: 4-20 mA (3-wire), 0-5 or 0-10 Vdc (field selectable)
Ambient Operating Range: 32 to 122°F (0 to 50°C), 5 to 90 %RH non-condensing
Enclosure: ABS, IP30 (NEMA 1)
