Room Humidity Transmitter and Temperature Sensor PL-RM-TRH-LCD, PL-RM-TRH
The PL-RM-TRH features a temperature sensor and relative humidity transmitter for dual room temperature and humidity readings. The humidity transmitter uses a highly accurate and field-proven RH sensor in an attractive low profile enclosure to monitor room relative humidity levels.
Product Code: PL-RM-TRH*
*See "Screen Options" below for the right product code according to the desired configuration
Characteristics
Humidity Sensor: Thermoset polymer based capacitive
Accuracy: ±5 %RH (5 to 95 %RH)
Range: 0 to 100 %RH
Output Signal: 4-20 mA, 0-5 or 0-10 Vdc (field selectable)
Temperature Sensor: 10,000 Ω Type 3, NTC Thermistor, ±0.2°C
Operating Conditions: 32 to 122°F (0 to 50°C)
Enclosure: White ABS, UL94-v0, IP30 (NEMA 1)
