Bluetooth Adapter PL-485-BT
The PL-485-BT provides either a Bluetooth wireless connection or a wired USB connection for Prolon’s configuration software tools. Apple® and Android® tablets or smartphones may connect, view, and configure a Prolon control system via Bluetooth 4.0 using Prolon’s free Focus applications. Windows® computers may use the PL-485-BT as a wired USB to RS485 converter for connection using Prolon’s Focus software. The PL-485-BT is the ideal tool for contractors and end users due to its simplicity and ease of use; it may be used as a portable, battery-powered tool, or it can be installed on site and powered via USB for permanent, local wireless access.
Product Code: PL-485-BT
Characteristics
- Wireless: Bluetooth Low Energy v.4.0, GFSK Protocol, 2.4 GHz, 1 Mbps
- RS-485: 2-Wire with removable screw-terminal block and custom RJ45 jack
- USB: USB 2.0 Type B wired connection
- Integrated LEDs for RS485 TX/RX, power status, and Bluetooth activity
- Battery life: 15 hours online/22 hours standby
- Empty battery fully charges in about 3 hours
- Physical on/off switch eliminates battery consumption when in off position
- Factory reset, passkey modification and more all available via software
Bluetooth Connection Requirements
- Apple iOS Version 9.0 or newer
- Android Version 4.3 (Jelly Bean) or newer
- Current Prolon Focus Android® or Apple® application installed on mobile device
- Device must be capable of Bluetooth 4.0
