Outside Humidity Transmitter PL-DT-RH
The PL-OA-RH outside humidity transmitter uses a highly accurate and reliable Thermoset Polymer based capacitance humidity sensor and state-of-the-art digital linearization and temperature compensated circuitry to monitor outside air humidity levels.
Product Code: PL-OA-RH
Characteristics
Sensor Type: Thermoset polymer based capacitive
Measurement Range: 0 to 100 %RH
Sensor Accuracy: ±5 %RH (5 to 95 %RH)
Ambient Operating Range: -40 to 140°F (-40 to 60°C)
Output Signal: 4-20 mA current loop, 0-5 Vdc, 0-10 Vdc, or 0-1 Vdc (fi eld
selectable)Enclosure: Polycarbonate, UL94-V0, IP65 (NEMA 4X), with cable gland
fitting
