Terminal VAV Boxes PL-TUB
The PL-TUB series boxes are an acoustic insulated, round in, square out damper terminal designed for Variable Air Volume (VAV) or Variable Volume and Temperature (VVT) zoning applications. You may also choose to have Prolon’s PL-FSD flow sensor pre-installed from the factory for pressure independent applications.
Product Code: PL-TUB-XX*
*See "Size Options" below for the right product code according to the desired configuration
Characteristics
Galvanized steel housings, satin finish (0.8 mm)
Single blade, dual density control damper with
Polyolefin insulation seal12.5 mm (1/2’’) internal fiberglass acoustic insulation covered with an acrylic layer and fiberglass reinforcement
Insulation complies with NFPA90A & 90B, SMACNA, Can/ULC S102-M88 and CGSB 51-GP-11M
12.5 mm (1/2”) shaft compatible with Prolon’s VC2000 series and most damper actuators
Outlet side of box has joints to allow connection of ductwork using standard S and Drive cleats
See the datasheet for detailed dimensional information on each size
