Air Differential Pressure Switch Kit PL-APS

Name: Webit Interactive
Price range: $

The differential pressure switch housing unit contains a diaphragm, a snap-acting SPDT switch, and a range adjustment knob with increments. The sample connections located on the side accept 0.25” (6.35mm) OD tubing. 2 pick up tubes and 6.56’ (2m) of PVC tubing are included. The enclosure cover guards against accidental contact with the live switch terminal screws and the setpoint adjustment knob with indication.

Product Code: PL-APS

Characteristics

Adjustment Range: 0.08” to 1.20” WC (20 to 300 Pa)
Switch Tolerance: ±15%
Operating Humidity Range: 0-95%, Non-Condensing
Diaphragm Material: Silicone, tempered at 200°C, free of gas emissions
Protection Category: IP54 with cover (NEMA 13)
Included Accessories: 6.56 ft (2 m) of PVC hose and 2 plastic tubes
Set of 3 push-on screw terminals
